Transmitter Solutions RAY318LIPW1V Visor Transmitter
SKU
ts-ray318lipw1v
The Transmitter Solutions RAY318LIPW1V is a 318 MHz one-button visor transmitter designed for use with Wiegand 26-bit programmable telephone entry, anti-burglar, and access control systems. Compatible with the Linear® MCT-1 / MDT-1.
Overview
The Transmitter Solutions® Stingray RAY318LIPW1V is a programmable visor transmitter operating at 318 MHz. It is designed for use with Wiegand 26-bit programmable telephone entry systems, anti-burglar systems, and access control systems requiring a 318 MHz input. Compatible with the Linear® MCT-1 / MDT-1.
Key Features
- 318 MHz operating frequency
- One Button (Blue)
- Visor model form factor
- Compatible with Linear® MCT-1 / MDT-1
- Programmable
- 5-Year Warranty
Specifications
- Supply: 1 Alkaline Battery 12V type 23A
- Battery Life: 12 – 18 months
- Current Consumption: 20 mA
- Code Combinations: 65,536
- Facility Codes: 16
- Modulation: AM / ASK
- Range in Free Space: 60 – 120 yd
- Operating Temperature: -20 ÷ +55 °C
- Overall Dimensions: 3.26 x 1.88 x 0.62 in
- Weight: 1 oz. (20 gr.)
Compatibility
- Linear® MCT-1
- Linear® MDT-1
Also available in a 2-button version: model 318LIPW2V.
