Transmitter Solutions RAY433TSPW2V Visor Transmitter
SKU
ts-ray433tspw2v
The Transmitter Solutions RAY433TSPW2V Stingray is a 2-button visor transmitter operating at 433 MHz, designed for use with Wiegand 26-bit programmable telephone entry, anti-burglar, and access control systems. Features long range performance and a 5-year warranty.
Overview
The Transmitter Solutions RAY433TSPW2V Stingray 433TSPW2V is a 433 MHz visor transmitter engineered for compatibility with Wiegand 26-bit programmable telephone entry systems, anti-burglar systems, and access control systems that operate with a 433 MHz input. The two-button maroon unit offers long range performance and is programmable.
Key Features
- 433 MHz operating frequency
- Two-button (Maroon)
- Visor model form factor
- Long range
- Programmable
- 5-year warranty
Specifications
- Supply: 1 Alkaline Battery, 12V type 23A
- Battery life: 12–18 months
- Current consumption: 20 mA
- Code combinations: 65,536
- Facility codes: 256
- Modulation: AM / ASK
- Range in free space: 60–120 yd
- Operating temperature: -20 ÷ +55 °C
- Overall dimensions: 3.26 x 1.88 x 0.62 in
- Weight: 1 oz. (20 gr.)
Also Available
- 1-button model: 433TSPW1V
- 4-button model: 433TSPW4V
The Transmitter Solutions RAY433TSPW2V delivers reliable long range 433 MHz access control performance in a compact visor form.
