Transmitter Solutions RAY433TSPW1V Visor Transmitter
The Transmitter Solutions RAY433TSPW1V (Stingray 433TSPW1V) is a 433 MHz one-button visor transmitter designed for Wiegand 26-bit programmable telephone entry, anti-burglar, and access control systems.
Overview
The Transmitter Solutions RAY433TSPW1V — also known as the Stingray 433TSPW1V — is a long-range visor transmitter operating at 433 MHz. It is engineered for use with Wiegand 26-bit programmable telephone entry systems, anti-burglar systems, and access control systems that accept a 433 MHz input. Backed by a 5-year warranty.
Key Features
- 433 MHz operating frequency
- One button (Maroon)
- Visor model form factor
- Long range performance
- Programmable
- 5-year warranty
Specifications
- Supply: 1 Alkaline Battery, 12V type 23A
- Battery life: 12 – 18 months
- Current consumption: 20 mA
- Code combinations: 65,536
- Facility codes: 256
- Modulation: AM / ASK
- Range in free space: 60 – 120 yd
- Operating temperature: -20 ÷ +55 °C
- Overall dimensions: 3.26 x 1.88 x 0.62 in
- Weight: 1 oz. (20 gr.)
Compatibility
Designed for use with Wiegand 26-bit programmable telephone entry systems, anti-burglar systems, and access control systems operating with a 433 MHz input. Also available in 2-button (433TSPW2V) and 4-button (433TSPW4V) versions.
The Transmitter Solutions RAY433TSPW1V delivers reliable long-range performance for professional access control applications.
