Transmitter Solutions RAY433TSPW4V Visor Transmitter
The Transmitter Solutions RAY433TSPW4V Stingray is a four-button visor transmitter operating at 433 MHz, designed for use with Wiegand 26-bit programmable telephone entry, anti-burglar, and access control systems.
Overview
The Transmitter Solutions RAY433TSPW4V Stingray 433TSPW4V is a long-range, four-button visor transmitter operating at 433 MHz. It is designed for compatibility with Wiegand 26-bit programmable telephone entry systems, anti-burglar systems, and access control systems that accept a 433 MHz input.
Key Features
- 433 MHz operating frequency
- Four-button configuration (Maroon)
- Visor model design
- Long range transmission
- Programmable
- 5-Year Warranty
Specifications
- Supply: 1 Alkaline Battery, 12V type 23A
- Battery Life: 12–18 months
- Current Consumption: 20 mA
- Code Combinations: 65,536
- Facility Codes: 256
- Modulation: AM / ASK
- Range in Free Space: 60–120 yd
- Operating Temperature: -20 ÷ +55 °C
- Overall Dimensions: 3.26 x 1.88 x 0.62 in
- Weight: 1 oz. (20 gr.)
Compatibility
Designed for use with Wiegand 26-bit programmable telephone entry systems, anti-burglar systems, and access control systems operating with a 433 MHz input. Also available in 1-button (433TSPW1V) and 2-button (433TSPW2V) versions.
The Transmitter Solutions RAY433TSPW4V delivers reliable long-range performance backed by a 5-year warranty.
