HySecurity S-SAP-1-CB StrongArmPark DC 14 Barrier Arm Operat
The HySecurity S-SAP-1-CB StrongArmPark DC 14 is a continuous duty electromechanical barrier arm operator supporting arms up to 14 ft, with built-in UPS backup and Smart DC controller. Boom sold separately.
Overview
The HySecurity S-SAP-1-CB StrongArmPark DC 14 is an electromechanical barrier arm operator engineered for continuous duty cycle operation in parking and traffic control applications. Capable of cycling arms up to 14 ft, it is suited for high-volume parking garages, private lots, gated communities, and commercial traffic control sites. The integrated UPS backup and Smart DC controller make it a dependable solution for demanding access control environments. Boom sold separately.
Key Features
- Electromechanical continuous duty (100% duty cycle) barrier arm operation
- Built-in UPS backup: 2 × 12V, 8Ah batteries providing over 1,000 cycles after AC power loss*
- HyProtect breakaway arm bracket reduces downtime after impacts
- Smart DC controller with 70+ user-configurable settings
- Field-adjustable open/close speeds: 2.5, 3, or 3.5 seconds
- Configurable fail state: fail open or secure after battery depletion
- Durable zinc-plated and powder-coated finish
- Operates in extreme temperatures from -13°F to 158°F (-25°C to 70°C) without a heater
- ETL Listed, UL 325 compliant for Usage Class I, II, III, and IV
- Tested for over 2 million operating cycles
- Handing: Left hand standard, right hand available
- Communication: USB, RS-232, RS-485, Ethernet/fiber via optional HyNet Gateway
- 1 configurable user relay (250VAC, 10A); optional Hy8Relay expansion adds 8 outputs
- Accessory power: 12VDC and 24VDC, 1A each
Specifications
- Model: S-SAP-1-CB (StrongArmPark DC 14)
- Drive Type: Electromechanical
- Duty Cycle: Continuous (100%)
- Maximum Arm Length: 14 ft
- Full Open Angle: 90° ± 10°
- Operating Time: 2.5 / 3 / 3.5 seconds (field adjustable)
- Power Input: 115VAC 3A or 208–230VAC 1.5A, 60/50Hz
- Input Voltage: 24VDC
- UPS Backup: 2 × 12V, 8Ah batteries
- Temperature Range: -13°F to 158°F (-25°C to 70°C)
- UL 325 Usage Class: Class I, Class II, Class III, Class IV
- Cycle Rating: Tested to 2 million cycles
- Warranty: 2 years
Compatible Barrier Arms
- 8 ft Barrier Arm
- 9 ft Barrier Arm
- 10 ft Barrier Arm
- 12 ft Barrier Arm
- 14 ft Barrier Arm
The HySecurity S-SAP-1-CB StrongArmPark DC 14 delivers proven reliability and flexible configuration for high-traffic vehicle access control installations.
