LiftMaster CSW200501UL 1/2 HP Swing Gate Opener
The LiftMaster CSW200501UL is a heavy-duty commercial swing gate operator designed for high-traffic applications. Built with advanced safety features, secure encrypted access, and myQ® connectivity with 828LM, it provides reliable and efficient gate automation for commercial properties.
LiftMaster CSW200501UL Heavy-Duty Commercial Swing Gate Operator
The LiftMaster CSW200501UL is a heavy-duty commercial swing gate operator engineered for high-traffic applications. Designed to handle gates up to 18 ft and 1,600 lbs, it delivers powerful, reliable performance with a continuous-duty high-temperature motor and rugged gear-driven transmission.
Built with LiftMaster’s legacy Elite™ commercial platform, the CSW200501UL combines durability, advanced safety features, and smart connectivity. It is ideal for commercial properties requiring consistent, secure, and long-lasting gate operation.
Key Features
- Handles swing gates up to 18 ft and 1,600 lbs
- Continuous-duty high-temperature motor for demanding applications
- Legacy Elite™ gear-driven transmission for maximum reliability
- Dual oil-bath gearboxes with 900:1 wormgear reduction
- Surge suppression protects against lightning strikes up to 50 ft away
- Smooth operation with gate opening in 13–15 seconds (90°)
- 5-year commercial warranty
Smart Features
- myQ® enabled for remote monitoring and control
- Wireless dual-gate communication eliminates trenching costs
- Synchronized close ensures both gate leaves close properly
- Supports up to 50 remotes (expandable with 811LM/813LM)
- LED diagnostic display simplifies setup and troubleshooting
- Programmable auxiliary relays for accessory integration
Note: myQ® functionality requires the 828LM Internet Gateway (sold separately).
Safety & Security
- Security+ 2.0® encrypted radio protects property access
- Inherent reversing sensor detects obstructions and reverses or stops gate
- Pre-motion warning alarm activates 3 seconds before gate movement
- Quick Close and Anti-Tailgate prevent unauthorized access
- Emergency manual disconnect allows gate operation during power loss
- UL® listed with monitored safety entrapment protection devices
- Monitored safety inputs (3 main board, 3 expansion board)
Included Accessories
- LMRRUL Monitored Retro-Reflective Photo Eye (50 ft range)
Mechanical Specifications
- Motor: 1/2 HP continuous-duty high-temperature motor
- Drive: Gear-driven system
- Gear System: Dual oil-bath gearboxes with 900:1 wormgear reduction
- Duty Rating: Continuous duty (high-cycle, high-temperature)
Power
- 115V single-phase
- Accessory Power: 24VDC 500mA output
- Optional 3PHCONV kit converts 3-phase input to 115VAC
Commercial-Grade Design
- 1/4" gold zinc-plated steel chassis for corrosion resistance
- High-density, 2-piece UV-resistant polyethylene cover
- UL® usage classification: I, II, III, IV
- Operator weight: 175 lbs
Performance
- Gate Speed: Opens 90° in 13–15 seconds
- Maximum Gate Length: 18 ft
- Maximum Gate Weight: 1,600 lbs
Dimensions & Weight
- Height: 28.04"
- Width: 16.37"
- Depth: 19.59"
- Weight: 175 lbs
Temperature Specifications
- Without heater: -4°F to 140°F
- With optional heater (HTRNB): -40°F to 140°F
Standard Features
- Bi-part delay ensures primary gate closes last
- Mechanical limit system maintains position after manual disconnect
- On-board Security+ 2.0® radio receiver
- Expandable monitored safety inputs
Compatibility
- HomeLink® compatible (bridge may be required)
The LiftMaster CSW200501UL delivers commercial-grade durability, advanced safety, and smart control, making it a dependable solution for high-cycle swing gate applications.
