LiftMaster CSW200101ULMC Swing Gate Operator
The LiftMaster CSW200101ULMC is a 1 HP, 120VAC, single-phase swing gate operator engineered for continuous duty, high-traffic applications including large gated communities, commercial complexes, and private estates.
Overview
The LiftMaster CSW200101ULMC is a heavy-duty swing gate operator built for high-traffic environments such as gated communities, commercial facilities, and large private properties. Featuring a powerful 1 HP continuous-duty high-temperature P3 motor with Class H insulation, it is engineered for demanding, high-cycle applications.
Designed on LiftMaster’s proven Elite™ platform, this operator combines rugged construction, advanced safety features, and smart connectivity. A high-density, UV-resistant polyethylene cover protects internal components, ensuring long-term durability in harsh environments.
Key Features
- Continuous-duty high-temperature motor designed for high-cycle applications
- Legacy Elite™ heavy-duty gear-driven transmission for maximum reliability
- Dual oil-bath gearboxes with 900:1 wormgear reduction
- Soft mid-travel reversal extends hardware life
- Surge suppression protects against lightning strikes up to 50 ft away
- High-speed precision limit switches for accurate operation
- Timer-to-Close adjustable from 0–180 seconds
- 2 auxiliary power outlets for accessories
- 5-year commercial warranty
Smart Features
- myQ® Technology enables remote monitoring and control
- Wireless dual-gate communication eliminates trenching costs
- Synchronized close ensures proper dual gate operation
- Security+ 2.0® encrypted radio system with extended range
- Supports up to 50 remotes (expandable with 811LM/813LM)
- 2-digit LED diagnostic display simplifies troubleshooting
- Programmable auxiliary relays for accessory integration
Note: myQ® functionality requires the 828LM Internet Gateway (sold separately).
Safety & Security
- Inherent reversing sensor detects obstructions and reverses or stops the gate
- Pre-motion warning alarm activates 3 seconds before movement
- Quick Close and Anti-Tailgate prevent unauthorized access
- Emergency manual disconnect maintains limit position once reengaged
- UL® listed with monitored safety entrapment protection devices
- Monitored safety inputs (3 main board, 3 expansion board)
Included Accessories
- LMRRUL Monitored Retro-Reflective Photo Eye (50 ft range)
Mechanical Specifications
- Motor: 1 HP continuous-duty high-temperature motor (Class H insulation)
- Drive: Gear-driven system
- Gear System: Dual oil-bath gearboxes with 900:1 wormgear reduction
- Duty Rating: Continuous duty (high-cycle, high-temperature)
Power
- 115V single-phase
- Accessory Power: 24VDC 500mA output
- Optional 3PHCONV kit converts 3-phase input to 115VAC
Commercial-Grade Design
- 1/4" gold zinc-plated steel chassis for corrosion resistance
- High-density, 2-piece UV-resistant polyethylene cover
- UL® usage classification: I, II, III, IV
- Operator weight: 175 lbs
Performance
- Gate Speed: Opens 90° in 13–15 seconds
Dimensions & Weight
- Height: 27.99"
- Width: 15.20"
- Depth: 24.75"
- Weight: 175 lbs
Temperature Specifications
- Without heater: -4°F to 140°F
- With optional heater (HTRNB): -40°F to 140°F
Suitable Gate Dimensions
- 12 ft. x 2,000 lbs
- 16 ft. x 1,600 lbs
- 18 ft. x 1,400 lbs
- 22 ft. x 1,000 lbs
Replaces part numbers: CSW200, CSW200101U, CSW200101UL
The LiftMaster CSW200101ULMC delivers commercial-grade strength, advanced safety features, and smart connectivity—making it an ideal solution for high-cycle, heavy-duty swing gate applications.
