LiftMaster CSW24UL 24VDC Commercial Swing Gate Operator
The LiftMaster CSW24UL is a high-cycle swing gate operator with brushless DC motor that handles gates up to 1,600 lbs. or 18 feet, featuring battery backup and solar compatibility for reliable automation in residential, commercial, and industrial applications.
LiftMaster CSW24UL Commercial Swing Gate Operator
Commercial Swing Gate Operator with Battery Backup
The LiftMaster CSW24UL is a professional-grade swing gate operator designed for residential and light commercial applications. Built for commercial-duty performance, this operator delivers reliable and consistent operation for a wide range of installations.
Powered by a 0.5 HP, 24VDC continuous-duty motor, the CSW24UL provides smooth and efficient operation. Its integrated battery backup ensures uninterrupted access during power outages.
Key Features
- Commercial-Duty Performance: Designed for consistent operation in residential and light commercial applications.
- Battery Backup Included: Provides up to 146 cycles or up to 24 days of standby power during outages.
- Heavy-Duty Construction: Zinc-plated steel chassis with a NEMA-rated enclosure for weather protection.
- Smart Connectivity: MyQ® capability available with the addition of the 828LM Internet Gateway.
Included Accessories
- LMRRUL Monitored Retro-Reflective Photo Eye: Maximum range: 50 ft.
Mechanical & Electrical Specifications
- Motor: 24VDC continuous industrial-duty (0.5 HP equivalent)
- Operator Duty Rating: Commercial-duty, high-temperature rated
- Gear System: Dual commercial oil-bath gearboxes with 900:1 worm gear reduction
- Power Input: 120/230VAC single-phase
- Three-Phase Option: Optional 3PHCONV converts 208/230/460/575VAC to 120VAC
- Accessory Power Output: 24VDC, 500mA max
- Battery Backup: Included
Solar Compatibility
- Solar Ready: For solar applications, use the LM-40W33AH 24V Solar Kit (sold separately).
Recommended Gate Capacities
- Up to 8 ft: 1,600 lbs.
- Up to 16 ft: 800 lbs.
- Up to 18 ft: 600 lbs.
Note: Gate capacity ratings do not account for wind load, gate design, or site conditions. Solid panel gates or high-wind areas will significantly reduce allowable gate size and weight.
Dimensions
- Height: 27.99""
- Width: 19.63""
- Depth: 15.55""
The LiftMaster CSW24UL provides dependable, commercial-grade gate automation with reliable performance and advanced functionality.
