LiftMaster RSW12UL 12V DC Smart Swing Gate Operator
The LiftMaster RSW12UL is a smart DC motor swing gate operator that handles gates up to 16 feet or 1,000 pounds, featuring MyQ® app control, battery backup for up to 147 cycles during outages, and solar compatibility for reliable residential and light commercial use.
LiftMaster RSW12UL Swing Gate Operator
Smart and Reliable Swing Gate Operator
The LiftMaster RSW12UL is a powerful DC-powered swing gate operator designed for residential and light commercial applications. Built for reliable performance, this operator provides smooth operation and dependable access control for a wide range of gate types.
This unit features an integrated battery backup system, providing up to 147 cycles during power outages. It is also solar compatible, making it a great option for off-grid or energy-conscious installations. For solar applications, the LM-20W33A 12V Solar Kit is recommended (sold separately). Smart control via MyQ® is available when paired with the optional 828LM Internet Gateway, allowing you to monitor and control your gate remotely.
Key Features
- Battery Backup Included: Provides up to 147 cycles during power outages.
- Optional Smart Control: MyQ® capability available with the addition of the 828LM Internet Gateway.
- Included Safety Device: Comes with LMRRUL monitored retro-reflective photo eye for UL 325 compliant protection.
- Solar Ready: Compatible with solar power setups for off-grid applications.
- Commercial-Duty Performance: Designed for consistent use in residential and light commercial environments.
Mechanical Specifications
- Motor: 12VDC continuous-duty
- Operator Duty Rating: 250 cycles per day
- Operator Weight: 180 lbs.
Technical Specifications
- Power Supply: 120VAC input / solar compatible
Recommended Gate Capacities
- Up to 6 ft: 1,000 lbs.
- Up to 10 ft: 700 lbs.
- Up to 16 ft: 400 lbs.
Note: Gate capacity ratings do not account for wind load, gate design, or site conditions. Solid panel gates or high-wind areas will significantly reduce allowable gate size and weight.
Dimensions
- Height: 27.99""
- Width: 15.55""
- Depth: 19.63""
Additional Requirements
- Expansion Board: The K1D8387-1CC Expansion Board is required if adding loops, auxiliary devices, or additional inputs.
The LiftMaster RSW12UL delivers dependable swing gate automation with the flexibility of battery backup, solar compatibility, and optional smart control for modern installations.
