Viking Access Systems T21NX T21 Swing Gate Operator Commerci - Operator Only
The Viking Access Systems T21NX is a commercial swing gate operator built on a 1/4" steel chassis with multi-layer corrosion protection, supporting gates up to 2000 lbs at 12 ft with a 100% duty cycle and true battery backup included. Operator only; accessories sold separately.
Overview
The Viking Access Systems T21NX T21 Swing Gate Operator features a 1/4" steel chassis with multi-layer corrosion protection engineered for reliable, long-lasting performance in demanding environments. Operating at 24VDC with support for 120VAC or 240VAC input power, this operator delivers a 100% duty cycle and handles gate capacities up to 20 ft at 1200 lbs or 12 ft at 2000 lbs. A removable power supply box with LED indicators communicates with the V-Flex™ LCD screen, displaying AC line status, surge protection status, and fuse condition at a glance.
Key Features
- 1/4" steel chassis with multi-layer corrosion protection
- Adaptive motor control
- 100% duty cycle
- Built-in thermostat controlled heater
- Built-in loop rack
- Built-in voltmeter
- V-Flex™ LCD on-board display showing AC line, surge protection, and fuse status
- True battery backup — 400 continuous cycles
- Two 6Ah batteries included
- Adjustable speed control
- Smooth start / stop operation
- Anti-tailgating feature
- Fail secure mode
- Mechanical manual release
- Two monitoring inputs with up to 4 devices per input
- 120V outlet provided
- Multiple power options including 24VAC/VDC (60VA) or Solar
- Multiple power outage options
- Lightning strike protection built in
- UL 325 compliant — Class I, II, III, IV
Specifications
- Maximum Gate Capacity: 20 ft at 1200 lbs / 12 ft at 2000 lbs
- UL 325 Classification: Class I, II, III, IV
- Duty Cycle: 100%
- Operating Voltage: 24VDC
- Input Voltage / Current: 120VAC – 3.0A or 240VAC – 1.5A
- Main Power Frequency: 50Hz / 60Hz
- Main Power Fuse: 4A Timed
- Alternative Power Source: 24VAC/VDC (60VA) or Solar
- Accessory Power: 24VDC – 750mA
- Motor Current (Typical): 5.0A
- Power Consumption – Sleep: 28mA
- Operating Temperature: -20°F (-28°C) to 160°F (71°C)
- Opening Angle: 120°
- Gate Speed: 13–16 sec./90°
- Battery Backup: 400 continuous cycles
The Viking Access Systems T21NX is a dependable commercial swing gate operator built to perform where it counts.
What's Included
- (1) T21 Swing Gate Operator
This listing is for the gate operator only. Remotes, receivers, photocells, and other accessories are sold separately.
