LiftMaster CBG24DC Techna DC Barrier Gate Operator
The LiftMaster CBG24DC TECHNA DC Barrier Gate Operator features a 24V brushless DC direct-drive motor, built-in Wi-Fi and Ethernet, and myQ Facility integration — supporting arms up to 14 ft with a 2.5-second open/close cycle.
Overview
The LiftMaster CBG24DC TECHNA DC Barrier Gate Operator is a commercial-grade, continuous-duty barrier solution engineered for demanding access control environments. Powered by a 24V brushless DC direct-drive motor with a 303.5:1 gear reduction, it delivers a fast ~2.5-second open/close cycle and supports barrier arms up to 14 feet. Available in White (CBG24DCWMC) or Gray (CBG24DCGMC) powder-coated enclosures, the CBG24DC integrates seamlessly into modern access control infrastructure via built-in Wi-Fi and Ethernet with full myQ Facility compatibility for browser-based programming, event logging, and remote monitoring.
Key Features
- 24V Brushless DC Motor — Direct-drive, continuous-duty operation
- Wi-Fi and Ethernet Connectivity — Browser-based setup and control via myQ Facility
- myQ Facility Integration — Remote monitoring, event logging (50 onboard; unlimited via myQ), and browser-based programming
- ~2.5-Second Open/Close Cycle — Fast throughput for high-traffic vehicle lanes
- Supports Arms Up to 14 ft — Compatible with standard and LED-lit barrier arms
- LCD Control Interface — On-unit visual diagnostics and digital setup via 4-button menu
- Breakaway Arm Bracket — Enables quick recovery from impact
- Hood-Mounted Status Light — Built-in LED for operational visibility
- Battery Backup Included — Standard 2 × 12V 7Ah; optional 2 × 12V 33Ah
- IP65-Rated Enclosure — Powder-coated 10-gauge aluminum, rated for outdoor use
- UL 325 Compliant — Suitable for Class I–IV commercial applications; fire department access compliant
- Modular TECHNA Platform — Shared components across the TECHNA series simplify service and inventory
- Solar Ready
Specifications
- Motor Type: 24V Brushless DC, Continuous Duty
- Drive Type: Direct Gear Reduction (303.5:1)
- Horsepower: 0.5 HP
- Power Input: 115V / 230V, Single-Phase
- Frequency: 310 / 315 / 390 MHz
- Max Arm Length: 14 ft
- Cycle Speed: ~2.5 seconds
- Operating Temperature: -4°F to 140°F (without heater); -40°F to 140°F (with heater)
- Enclosure: Powder-coated 10-gauge aluminum, IP65 rated
- Battery Backup: 2 × 12V 7Ah (standard); 2 × 12V 33Ah (optional)
- Event History: 50 events onboard; unlimited via myQ Facility
- Connectivity: Wi-Fi, Ethernet; built-in cellular available (subscription required)
- Color Options: White (CBG24DCWMC), Gray (CBG24DCGMC)
- Mounting Type: Pad Mounted
- Certifications: UL 325, Fire Department Access Compliant
- Weatherproof Rating: Rated for Outdoor Usage
Compatible Barrier Arms (Sold Separately)
- BGARM10 — 10 ft standard aluminum arm
- BGARM10LED — 10 ft arm with integrated red/green LED lighting
- BGARM12LED — 12 ft LED barrier arm
- BGARM14 — 14 ft standard barrier arm
- BGARM14LED — 14 ft arm with integrated red/green LED lighting
The LiftMaster CBG24DC is the professional-grade barrier gate operator for commercial, industrial, and community access control applications that demand speed, connectivity, and long-term reliability.
