Altronix 6062 Multi-Purpose Programmable Timer

Altronix 6062 Multi-Purpose Programmable Timer

The Altronix 6062 is a programmable timer board suitable for many functions requiring timed operation, including access control applications, siren/bell cut off, dialer delay, guard tour supervisory timing, and more. Optional functions include One Shot, Delayed Release, Delayed Operate, Delayed Pulse, and Pulser/Flasher modes.

Key Features

• Triggers via positive DC (+) voltage, dry contact closure, or removal of contact closure
• Quick and extremely accurate time range adjustment from 1 second to 60 minutes
• Selectable relay activation at the start or end of the timing cycle
• One (1) second momentary relay activation at the end of the timing cycle, eliminating the need for two timers
• Built-in reset feature which cancels the timing cycle
• Repeat (flasher/pulse) mode
• LED indicator shows when relay is energized

Specifications

• Input: 12VDC or 24VDC (selectable)
• Current Draw: Stand-by: 3mA; Relay energized: 40mA
• Operating Temperature: 0°C to 49°C (32°F to 120°F)
• Storage Temperature: -20°C to 70°C (-4°F to 158°F)
• Relative Humidity: 85% ±5%
• Dimensions (approximate): 2.5"W x 3"L

The Altronix 6062 delivers reliable, versatile timed operation for a wide range of security and access control applications.
