Security Brands 25-C2 Two-Door Cellular Access Control System
The Security Brands 25-C2 is a two-door cellular access control system with full 4G LTE connectivity, cloud-based management via the Summit Control platform, and an IP65-rated weather-resistant enclosure.
Cellular Access Control for Two Doors or Gates
The Security Brands 25-C2 Ascent C2 delivers secure, remote access management for up to two doors or gates through the Summit Control cloud platform. It supports app, text, and voice users alongside two Wiegand inputs, and connects via full 4G LTE with automatic network selection — all housed in a rugged, weather-resistant IP65-rated polycarbonate enclosure.
Key Features
- Full 4G LTE cellular connectivity with automatic network selection
- Controls up to 2 doors or gates
- Two Wiegand inputs for keypads, card readers, or other access devices
- Supports up to 10,000 app, text, and voice users (depending on plan)
- Push and email notifications for event and status updates
- Cloud-based management via Summit Control platform
- Remote access app and remote unlock capability
- Modular configuration for multi-door setups
- IP65-rated rugged polycarbonate housing
- Power supply included
Specifications
- Power Input: 12–24 VAC/DC
- Current Draw: <330 mA @ 12VDC; <160 mA @ 24VDC
- Relay Contact Rating: 10A @ 120VAC / 24VDC
- Max Switching Voltage: 250VAC / 30VDC
- Max Switching Current: 15A
- Max Switching Power: 240W / 2,770VA
- Cellular Network: 4G LTE
- Operating Temperature: -15°F to 158°F (-26°C to 70°C)
- Enclosure Rating: IP65-rated polycarbonate housing
- Dimensions: 12.8" H × 8.65" W × 6.0" D
- Shipping Weight: 6 lbs
The Security Brands 25-C2 is a dependable cellular access controller built for commercial, industrial, and community installations requiring flexible, cloud-managed dual-door or gate control.
