Transmitter Solutions DOLCWIUHF-ER902-W Long Range Reader
SKU
ts-dolcwiuhf-er902-w
The Transmitter Solutions DOLCWIUHF-ER902-W is a UHF extra long range reader operating at 902 MHz with a read range of up to 60 feet, housed in a white enclosure with 26-bit Wiegand output and FCC certification.
Overview
The Transmitter Solutions DOLCWIUHF-ER902-W is a white-housing UHF reader designed for extra long range access control applications. Operating at 902–928 MHz using FHSS transmission, it delivers a read range of up to 60 feet in open space and carries FCC certification. An indicator light is included on the reader for easy status monitoring.
Key Features
- Read range up to 60 feet
- 26-bit Wiegand output
- FCC Certified
- Simple to install
- Indicator light on reader
- Available in black or white housing
Specifications
- Operating Frequency: 902–928 MHz
- Transmission Type: FHSS
- Detection Range (open space): up to 60 feet
- Power Supply: 12 Vdc
- Active Mode Current: 1A @ 12 Vdc
- Stand-by Max Current: 200 mA @ 12 Vdc
- Operating Temperature: -4°F to 131°F
- Storage Temperature: -40°F to 185°F
- Operating Humidity: <95% RH (at 77°F)
- Weight: 4 lb. 13 oz.
- Protocol Tag Supported: ISO 18000-6C/6B
- RF Output Power: Up to 33 dBm (adjustable)
- Polarization: Circular
- Output: RS-485
- Dimensions: 12 x 12 x 3.15 in.
- IP Class: IP65
- Housing Color: White
Compatible Credentials
- UHF Sticker — Part No: CARMANSTIUHF-ST
- UHF Card Holder — Part No: CARMANISOUHF
- UHF Duo Card Holder — Part No: CARMANISODUOUHF
- UHF On-metal Label V2 — Part No: MANUHFOL V2
- UHF Sticker — Part No: CARMANSTIUHF
- UHF Hang Tag — Part No: CARMANHT
- License Plate Tag — Part No: CARMANLP
The Transmitter Solutions DOLCWIUHF-ER902-W delivers professional-grade long range UHF reading performance in a weatherproof IP65-rated white enclosure.
