Transmitter Solutions IGAZESR196HD Long Range Photo Eyes
SKU
ts-igazesr196hd
The Transmitter Solutions IGAZESR196HD is a UL 325 long range, vandal resistant infrared photo eye featuring a shock-proof thermoplastic rubber case, IP55 protection, and self-centering design.
Overview
The Transmitter Solutions IGAZESR196HD is a UL 325 compliant long range, vandal resistant infrared photocell designed for demanding access control applications. It features a self-centering design, IP55 protection, and a shock-proof thermoplastic rubber case built to withstand tough environments.
Key Features
- Infrared photocell with GA AS diode emission
- Self-centering alignment
- IP55 environmental protection
- Shock-proof thermoplastic rubber case
- 196 ft indoor range
- 65 ft outdoor range
- NO and NC contacts with double relay in series
- UL 325 compliant
Specifications
- Emission: Infrared with GA AS diode
- Wavelength: 950 nM
- Continuous Modulation: 1.33 KHz
- Power Requirements: 12/24 VAC/VDC (depending on jumper insertion)
- Absorption: 110 mA to 24 VAC (TX+RX)
- Operating Temperature: 14°F to 140°F
- Contact: NO and NC with double relay in series
- Max Relay Contact Power: 1A to 24 VAC (resistive load)
- Indoor Range: 196 ft
- Outdoor Range: 65 ft
The Transmitter Solutions IGAZESR196HD delivers reliable long range infrared detection in a vandal resistant, weather-protected housing built for professional access control installations.
