Viking Access Systems I770DLK Underground Swing Dual Kit
The Viking Access Systems I770DLK is an underground dual leaf swing gate operator kit supporting gates up to 12 ft at 650 lb, powered by the V-Flex control board with speed control and diagnostic LCD display.
Overview
The Viking Access Systems I770DLK Underground Swing Gate Operator Kit delivers a nearly invisible dual leaf swing gate solution. The direct-drive DC gearhead unit is IP67 water-resistant and features a stainless-steel chassis. ETL Listed and compliant with UL325 and UL991, the I770DLK is powered by the V-Flex control board, which includes speed control and a diagnostic LCD display. The operator is solar efficient and ready for low voltage wiring, allowing versatility of installations. A 3-year manufacturer's warranty is included.
Kit Includes
- (2) VA-I770 or VA-I770S — Inground Swing Gate Operator
- (1) VA-ECUD2 — ECU Dual Controller for Kits
- (1) FA-XR2C — 433 MHz Receiver
- (2) FA-XT4RC — 433 MHz RC Transmitter
- (1) FA-XP30-10K — Photocell 10K Resistor
- (2) FA-XP30AC — Photocell Adapter
- (1) DJBK — Junction Box
- (40 ft) VA-CB16 — 6-Conductor Cable, 16 AWG Shielded
Key Features
- Adaptive motor control
- Built-in thermostat-controlled heater
- Built-in voltmeter
- Lightning strike protection
- Multiple power options
- On-board display
- Anti-tailgating feature
- Fail secure mode
- Large box option
- Mechanical manual release
- Multiple power outage options
- Positive stop limits
- Battery backup: 400 continuous cycles
- Two monitoring inputs with up to 4 devices per input
- Alternative power source: 24VAC/VDC (60VA) or Solar
- Adjustable speed control
Specifications
- Maximum Gate Capacity: 12 ft at 650 lb
- UL 325 Classification: Class I, II, III, IV
- Duty Cycle: 100%
- Operating Voltage: 24VDC
- Voltage Current Specs: 120VAC - 1.5A or 240VAC - 1.0A (each motor)
- Main Power Frequency: 50Hz / 60Hz
- Main Power Fuse: 4A Timed
- Operating Temperature: -20°F (-28°C) to 131°F (55°C)
- Opening Angle: 110°
- Gate Speed: 13–15 sec./90°
- Battery Backup: 400 continuous cycles
- Accessory Power: 24VDC - 750mA
- Power Consumption – Sleep: 28mA
- Motor Current (Typical): 3.0A
- IP Rating: IP67
- Manufacturer's Warranty: 3 years
The Viking Access Systems I770DLK is a professional-grade underground swing gate solution engineered for reliable dual leaf operation across demanding installations.
