Viking Access Systems VFLEXPCB-H10 Control Board

Replacement Control Board for Viking H10 Slide Gate Operators

The Viking Access Systems VFLEXPCB-H10 is the black-sticker legacy control board built exclusively for the Viking H10 Slide Gate Operator. It reflects pre-2016 UL safety behavior and basic diagnostic functions, and is identified by its black sticker color for correct replacement matching.

Key Features

• H10 Exclusive: Engineered specifically for Viking H10 Slide Gate Operators
• Surge Protection: Guards against surges up to 20,000 volts / 10,000 amps
• LCD Display: Provides real-time error codes and motor current readings
• Adaptive Motor Control: Automatically optimizes torque and speed for smooth operation
• Battery Backup: Supports up to 400 complete cycles during power outages on a 600 lb gate
• UL325 Compliant: Includes obstruction detection and monitored entrapment protection
• All-Weather Operation: Thermostat-controlled heater rated for environments as cold as -20°F
• Direct-Mounted installation type

Specifications

• Operating Voltage: 24VDC
• Input Power: 120/240VAC single-phase
• Surge Protection: 20,000 volts / 10,000 amps
• Fuse Rating: 20A motor fuse (specific to H10 operator)
• Battery Backup Cycles: Up to 400 cycles (600 lb gate)
• Temperature Range: -20°F to 160°F
• Display: LCD screen with live error feedback and diagnostics
• Compliance: UL325 Certified
• Mounting Type: Direct-Mounted

Compatibility

The VFLEXPCB-H10 is designed exclusively for the Viking H10 Slide Gate Operator. It is identified by a black sticker and corresponds to pre-2016 UL compliance. It is not intended for use with other Viking models unless explicitly stated by the manufacturer.

The Viking Access Systems VFLEXPCB-H10 delivers reliable control board performance for pre-2016 Viking H10 Slide Gate Operator installations.
