Transmitter Solutions IGAZESR33HD Vandal Resistant Photo Eye
SKU
ts-igazesr33hd
The Transmitter Solutions IGAZESR33HD is a UL Select vandal-resistant infrared photo eye with send/receive operation, IP55 protection, and a range of up to 49 feet. Designed for industrial use with adjustable optics and double rubber seal.
Overview
The Transmitter Solutions IGAZESR33HD is a vandal-resistant infrared photo eye rated UL Select and built for industrial environments. It features a send/receive design with adjustable optics, IP55 protection, and a double rubber seal for durability in demanding conditions.
Key Features
- Anti-vandal construction for industrial use
- Adjustable optics: +/- 90° horizontally and +/- 15° vertically
- IP55 protection rating
- Double rubber seal
- Infrared send/receive operation
- Range: 26 feet (Low) / 49 feet (High)
- UL Select rated
Specifications
- Power Supply: 12/24 VAC/DC
- Operating Temperature: 5° to 140° F
- TX Consumption: 65 mA at 24 VAC
- RC Consumption: 30 mA at 24 VAC
- Wave Length: 950 nm
- Modulation: 1.33 KHz
- Current commutable by relay: 1 A at 24 V
- Range: 26 Feet (Low) / 49 Feet (High)
The Transmitter Solutions IGAZESR33HD delivers reliable infrared detection with industrial-grade vandal resistance and flexible mounting adjustment.
