Locinox VENUS-S-9005 Motorized Gate Closer Sliding Arm
The Locinox P00035920-9005 VENUS-S-9005 is a motorized gate closer with sliding arm, designed for pedestrian swing gates up to 1400 mm (4 ft) wide and 100 kg (220 lbs), featuring a brushless motor and integrated obstacle detection.
Overview
The Locinox P00035920-9005 VENUS-S-9005 is a motorized gate closer with sliding arm engineered for pedestrian swing gates. Accommodating gates up to 1400 mm wide and 100 kg, it combines an all-in-one design with integrated electronics, power supply, circuit board, input/output connectors, and an indicator light — all in a compact, vandal-proof enclosure.
Key Features
- Brushless motor for long lifespan and intensive usage
- Automated obstacle detection with reverse function for safe operation
- Reversible motor with backdrivability for easy manual use — to be combined with a lock
- Integrated warning light
- Low-energy speed control for reliable, safe performance
- Easy setup via free mobile app
- Quick-Fix mounting system for straightforward installation
- Steel gear box with anodized aluminium cover
- Compact and vandal-proof design
Specifications
- Motor voltage: 24V DC
- Input power supply: 115V AC (60 Hz) to 230V AC (50 Hz)
- Maximum gate width: 1400 mm (4 ft)
- Maximum gate weight: 100 kg (220 lbs)
- Finish: Black (RAL 9005)
- Gear box: Steel
- Cover: Anodized aluminium
Compatibility
Designed for pedestrian swing gates. The reversible motor with backdrivability is intended to be combined with a lock.
The Locinox P00035920-9005 VENUS-S-9005 delivers professional-grade automated gate closing in a durable, all-in-one package built for demanding outdoor environments.
