Viking Access Systems VFLEXPCBU18-H10 Control Board
The Viking Access Systems VFLEXPCBU18-H10 is a direct-mounted replacement control board engineered exclusively for the Viking H10 Slide Gate Operator, featuring UL325 compliance, LCD diagnostics, and surge protection up to 20,000 volts / 10,000 amps.
Viking Access Systems VFLEXPCBU18-H10 Control Board Overview
The Viking Access Systems VFLEXPCBU18-H10 is the current-production Orange control board designed exclusively for the Viking H10 Slide Gate Operator. This post-2018 UL325-compliant board delivers improved diagnostics, upgraded surge protection, and requires a monitored photoeye. It is direct-mounted and operates on 120/240VAC single-phase input power with a 24VDC operating voltage.
Key Features
- H10 Exclusive Compatibility: Engineered specifically for the Viking H10 Slide Gate Operator.
- Enhanced Surge Protection: Guards against surges up to 20,000 volts / 10,000 amps.
- LCD Diagnostics: Provides real-time error codes, system data, and motor current readings.
- Adaptive Motor Control: Automatically optimizes torque and speed for smooth operation.
- Battery Backup: Supports up to 400 complete cycles on a 600 lb gate during power outages.
- UL325 Compliant: Meets current safety standards with obstruction detection and monitored entrapment protection.
- All-Weather Operation: Thermostat-controlled heater supports reliable use from -20°F to 160°F.
- 20A Motor Fuse: Specific to the H10 operator.
Specifications
- Model: VFLEXPCBU18-H10
- Operating Voltage: 24VDC
- Input Power: 120/240VAC single-phase
- Surge Protection: 20,000 volts / 10,000 amps
- Fuse Rating: 20A motor fuse
- Battery Backup Cycles: Up to 400 cycles (600 lb gate)
- Temperature Range: -20°F to 160°F
- Display: LCD screen with live error feedback and diagnostics
- Mounting Type: Direct-Mounted
- Compliance: UL325 Certified
Compatibility
The VFLEXPCBU18-H10 is designed exclusively for the Viking H10 Slide Gate Operator. It is not intended for use with other Viking models unless explicitly stated by the manufacturer. This Orange board represents the post-2018 UL325 current production model. Other variants include the Green (VFLEXPCBU16-H10, 2016 UL325) and Black (VFLEXPCB-H10, pre-2016) boards — match your replacement by sticker color and UL compliance year.
The Viking Access Systems VFLEXPCBU18-H10 is the current-generation solution for maintaining or upgrading a Viking H10 Slide Gate Operator to modern safety and performance standards.
