Viking Access Systems 18MONITOR Wi-Fi Gate Controller

Overview

The Viking Access Systems 18MONITOR connects Viking gate openers to a 2.4 GHz Wi-Fi network, enabling remote control and real-time monitoring from anywhere through the Viking Monitor App. Compatible with V-Flex and E-4 control boards, it supports cloud-based access, USB data storage, and instant gate activity notifications. Replaces part number 0222-VM-13696.

Key Features

• Wi-Fi Connectivity: Operates within a 100-foot range on a 2.4 GHz network
• Viking Monitor App: Available for Android and iOS — provides real-time control and monitoring
• Cloud-Based Access: Remote diagnostics and instant alerts via the cloud
• USB Data Storage: Built-in USB port for storing operator data and history
• Real-Time Notifications: Instant alerts for gate openings, closings, and system issues

Specifications

• Wi-Fi Range: Up to 100 feet (2.4 GHz network required)
• Supported Wi-Fi Standards: 802.11 b/g/n — not compatible with 5 GHz networks
• Security Protocols: WEP, WPA, and WPA2 (including WPA2-PSK-AES)
• Current Draw: 150mA
• Dimensions: 4.02" without antenna, 5.542" with antenna
• Cable Length: 22.75"
• USB Support: Yes, for data storage and transfer

Compatibility

• Compatible with Viking V-Flex and E-4 control boards
• Not compatible with solar-powered gate openers

The Viking Access Systems 18MONITOR is an essential tool for professionals managing Viking gate automation systems with remote monitoring and control requirements.
