EMX Industries 2810-1 Vehicle Motion Detector
The EMX Industries 2810-1 is a single-piece vehicle motion detector featuring a 100' lead, direct burial compatible probe, and a wide power input range of 12-39 VDC or 12-27 VAC. Made in the USA with a 2-Year Limited Manufacturer Warranty.
Overview
The EMX Industries 2810-1 (VMD202) is a single-piece vehicle motion detector designed to be buried next to a driveway. Its slim profile houses the probe and electronics together, and the 100' lead probe cable is 5-wire direct burial rated. The optional VMD202-R sensitivity remote simplifies installation and fine-tuning, and once settings are programmed, the remote can be removed and reused across multiple installations.
Key Features
- Probe assembly and cable are water tight and direct burial compatible
- 100' lead with 5-wire direct burial probe cable
- Accepts 12-39 VDC or 12-27 VAC power input
- Low current consumption: 70 µA standby and 25 mA activated — suitable for solar power applications
- 10 sensitivity settings programmable via optional VMD202-R remote
- Settings stored in non-volatile memory — retained in the event of power failure
- Made in the USA
- 2-Year Limited Manufacturer Warranty
Specifications
- Power: 12-39 VDC or 12-27 VAC
- Current: 70 µA standby / 25 mA activated
- Relay: Form C (SPDT) 1 A @ 24 VDC, 1 A @ 120 VAC
- Operating Temperature: -30°C to 70°C (-22°F to 158°F)
- Humidity: 0 to 95% relative humidity
- VMD202-R Dimensions: 3.0 x 0.9 x 2.75 in
- Probe Dimensions: 1 x 24 in
- Material: ABS Plastic (VMD202-R), PVC (Probe)
- Probe Cable: 5-wire direct burial
- Manufacturer Part Number: EMX-2810-1
Replaces part number VMD202-5-100. The EMX Industries 2810-1 delivers reliable vehicle detection with durable, burial-ready construction and flexible power compatibility.
