EMX Industries 2805-1 Vehicle Motion Detector
The EMX Industries 2805-1 (VMD202) is a single-piece vehicle motion detector with a 50-foot lead, direct burial-compatible probe, and a wide power input range of 12–39 VDC or 12–27 VAC.
Overview
The EMX Industries 2805-1 is the VMD202 Vehicle Motion Detector, a single-piece detector designed to be buried next to a driveway. The probe and its electronics are housed in a slim design, and the unit ships with a 50-foot lead. The optional VMD202-R sensitivity remote makes installation and fine-tuning simple — once settings are programmed, the VMD202-R can be removed and reused across multiple installations.
Key Features
- Probe assembly and cable are water tight and direct burial compatible
- 5-wire direct burial probe cable
- Accepts 12–39 VDC or 12–27 VAC power input
- Low current consumption: 70 µA standby and 25 mA activated — suitable for solar power applications
- 10 sensitivity settings programmable via the optional VMD202-R remote
- Settings stored in non-volatile memory — retained in the event of power failure
- Made in USA
- 2-Year Limited Manufacturer Warranty
Specifications
- Model: 2805-1 (VMD202)
- Replaces part number: VMD202-5-50
- Power: 12–39 VDC or 12–27 VAC
- Current Draw: 70 µA standby / 25 mA activated
- Relay: Form C (SPDT) 1 A @ 24 VDC, 1 A @ 120 VAC
- Operating Temperature: -30°C to 70°C (-22°F to 158°F)
- Humidity: 0 to 95% relative humidity
- VMD202-R Housing Material: ABS Plastic
- Probe Material: PVC
- VMD202-R Dimensions: 3.0 x 0.9 x 2.75 in
- Probe Dimensions: 1 x 24 in
- Lead Length: 50 feet
The EMX Industries 2805-1 delivers reliable vehicle detection in a durable, burial-ready package built and warranted for demanding access control applications.
