EMX Industries 4010-2 Wireless Edge Receiver
The EMX Industries 4010-2 (WEL-200R) is a wireless safety edge receiver with a 200 ft. line-of-sight range at 915 MHz, supporting up to four transmitters and compliant with UL325-2018 standards.
Overview
The EMX Industries 4010-2 WEL-200R wireless edge receiver is part of the WEL-200 system, which provides a complete wireless solution for interfacing sensing edges with gate and door operators. By eliminating hardwired connections between the safety edge and the operator control box, it delivers reliable edge monitoring while meeting 2018 UL325 compliance requirements. The receiver connects with up to four transmitters and provides separate relay and pulse outputs for open and close edge functionality.
Key Features
- Operating range up to 200 ft. (line of sight)
- Connect up to 4 safety edge transmitters
- Compatible with NC, 10K and pulse monitored outputs
- NEMA 4X environmental rating
- UL325-2018 compliant
- OPEN and CLOSE relay outputs: Form C contacts (NO, COM, NC)
- OPEN and CLOSE pulsed outputs: Open collector transistor output (opto-isolated)
- 10K ohm resistive termination across NO contact (jumper selectable)
- Power protection via thermal fuse and MOV
- Red power LED / green channel LED indicators
- Channel mode selection switch to assign each channel to OPEN/CLOSE function
- Made in USA
- 2-Year Limited Manufacturer Warranty
Specifications
- Operating Frequency: 915 MHz
- Response Time: 100 ms
- Operating Temperature: -40°–60°C (-40°–140°F)
- Dimensions (L x W x H): 140mm (5.5") x 34mm (1.3") x 90mm (3.5")
- Weight: 200g (7 oz.)
- Connections: 12 terminals (18–26 AWG)
- Power Supply: 12–24 VAC/VDC
- Current Draw: 50 mA
- Environmental Rating: NEMA 4X
Compatibility
- Compatible with transmitters supporting 8.2K and 10K monitored safety edges
- Replaces part number WEL-200RX
The EMX Industries 4010-2 is a dependable, USA-made wireless edge receiver designed to simplify safety edge integration while maintaining full UL325-2018 compliance.
