Linear 0-205676 Proximity Reader with Keypad
The Linear 0-205676 is a stand-alone 125KHz proximity reader and keypad offering integrated door control for up to 2000 users. UL 294 Listed and compatible with Wiegand and Secured Series systems.
Overview
The Linear 0-205676 Prox.pad is a stand-alone proximity reader and keypad that mounts directly to a single-gang electrical box or most flat surfaces. It delivers standard access control functionality through two relays and two inputs for request to exit and door position monitoring. Using the proximity reader and keypad together raises the security level by requiring both credentials to grant access. The proximity reader can be mounted up to a maximum of 10 feet away from the Prox.pad unit itself.
Key Features
- Integrated door control, proximity reader, and keypad in one unit
- Supports up to 2000 users
- HID 26–37 bit format card compatibility
- Bi-color LED to indicate operation
- Fits over a single-gang electrical box; glass-mount option included
- Proximity reader mountable up to 10 feet from the Prox.pad
- UL 294 Listed
- Corporate 1000 compatible
- Secured Series and Wiegand compatible
Specifications
- Dimensions: 2.75" W x 5.25" H x 1.38" D
- Operating Voltage: 12 VDC only
- Temperature Tolerance: -20°F to 130°F
- Main Relay: Form C 4 amp SPDT
- Auxiliary Relay: Form C 1 amp SPDT
- Frequency: 125KHz
Compatibility
- Compatible with IEI access systems and most Wiegand systems
- Corporate 1000 compatible
- Secured Series compatible
- HID 26–37 bit format credentials
The Linear 0-205676 is a professionally installed proximity reader and keypad solution built for reliable, flexible access control deployments.
