EMX Industries 4011-2 Wireless Edge Transmitter
The EMX Industries 4011-2 (WEL-200T) is a wireless safety edge transmitter operating at 915 MHz with a range of up to 200 feet. Compatible with 8.2K and 10K monitored safety edges and UL325-2018 compliant.
Overview
The EMX Industries 4011-2 (WEL-200T) is the transmitter component of the WEL-200 wireless edge link system. It eliminates hardwired connections between safety edges and gate operator control boxes while maintaining compliance with 2018 UL325 monitoring standards. The transmitter operates at 915 MHz with a line-of-sight range of up to 200 feet and is compatible with both 8.2K and 10K monitored safety edges. Replaces part number WEL-200TX.
Key Features
- Wireless range: up to 200 ft. (line of sight)
- Operating frequency: 915 MHz
- Response time: 100ms
- Compatible with NC, 10K, and pulse monitored outputs
- Compatible with 8.2K and 10K monitored safety edges
- Connect up to 4 safety edge transmitters to one receiver
- NEMA 4X environmental rating
- UL325-2018 compliant
- Green transmit/status LED indicator
- Power protection: Thermal fuse
- Made in USA
- 2-Year Limited Manufacturer Warranty
Specifications
- Model: 4011-2 (WEL-200T)
- Operating Frequency: 915 MHz
- Operating Range: Up to 200 ft. (line of sight)
- Response Time: 100ms
- Power Supply: 3–3.6 VDC (2x AA batteries) (ANSI 15-LF, IEC-FR14505 (FR6))
- Battery Life: 2 years at 25°C
- Operating Temperature: -40°–60°C (-40°–140°F)
- Dimensions (L x W x H): 180mm (7.0") x 32mm (1.3") x 67mm (2.6")
- Weight: 170g (6 oz.)
- Connections: 2 terminals (18–26AWG)
- Environmental Rating: NEMA 4X
Compatibility
- Compatible with 8.2K and 10K monitored safety edges
- Compatible with NC, 10K, and pulse monitored outputs
- Designed for use with the EMX Industries WEL-200 wireless edge link system
The EMX Industries 4011-2 delivers a reliable, code-compliant wireless safety edge solution for gate operator installations.
