Wireless Wiegand G3 Universal Wireless Wiegand Point-to-Poin
The Wireless Wiegand G3 is a preconfigured wireless bridge pair that replaces the cable run between an access control panel and any connected device, transmitting Wiegand, OSDP, and RS-485 signals transparently over an encrypted 900 MHz radio link — no panel reprogramming required.
Overview
The Wireless Wiegand G3 eliminates the need for cable runs between an access control panel and remote hardware. The system ships as two preconfigured units: one connects to the existing access controller, the other connects to the gate or door hardware — reader, lock, relay, REX, door contact, or gate operator. Together they form an encrypted 900 MHz radio link that behaves exactly like a direct wired connection. The access control system sees no difference. No reprogramming, no software changes, and no panel modifications are required.
Commonly deployed at perimeter gates, long driveways, remote sites, historical buildings, parking systems, multi-building campuses, and construction sites where running cable is expensive, impractical, or impossible.
Key Features
- Transparent signal pass-through — Wiegand (4 to 80 bit), OSDP, RS-485, relay control, REX, and sensor signals transmitted without reconfiguration
- Encrypted 900 MHz radio link — AES 128 encryption with frequency-hopping for protection against interference and attacks
- Tens of miles of range — depending on environment and elevation; no line of sight required
- Superior penetration — operates through concrete walls, steel structures, underground levels, and 20+ floors of reinforced building
- Embedded display and web interface — for setup, diagnostics, and firmware updates
- Wi-Fi 802.11 b/g/n 2.4 GHz — onboard for management access
- USB Type-C port — for firmware updates
- Wall mount or Din rail mount (option)
Specifications
- Voltage: 12 or 24 VDC operation
- Current consumption: 0.2A @ 12 VDC, 0.1A @ 24 VDC
- Reader power: Pass-through — if powered with 24V, readers receive the same power
- Slave device outputs: Four (4) dry form "C" 1.5A rated relay outputs
- Slave device inputs: Four (4) relay control inputs (dry contact) from 0 to 5 VDC; One (1) input (dry contact) 0 to 5 VDC for local emergency relay opening
- Master device outputs: Eight (8) outputs (dry contact) from 0 to 5 VDC
- Master device inputs: Eight (8) inputs (dry contact) from 0 to 5 VDC
- Communication interfaces: Wi-Fi 802.11 b/g/n 2.4 GHz; Two (2) Wiegand ports from 4 to 80 bits; RS-485 (OSDP); USB Type-C for firmware update
- Encryption: AES 128
- Dimensions (D x H): 5.9" x 3.15" x 1.38" (150 x 80 x 35 mm) excluding antenna
- Weight: 5.36 oz (152g)
- Operating temperature: 40°F ~ 149°F (-40°C ~ 65°C)
- Storage temperature: -40°F ~ 158°F (-40°C ~ 70°C)
- Relative humidity: 5–85% RH without condensation
- Ingress protection rating: IP 20
- Mounting: Wall mount / Din rail mount (option)
Compatibility
Compatible with controllers and gate operators from HID Mercury, Lenel, Brivo, Software House, Genetec, Honeywell, Bosch, ZKTeco, Suprema, Paxton, LiftMaster, DoorKing, Linear, and any system using Wiegand, OSDP, or RS-485.
For how-to videos and full documentation, visit wireless-wiegand.com.
