Viking Access Systems X390 Swing Gate Operator - Operator Only

Overview

The Viking Access Systems X390 Swing Gate Operator delivers professional-grade performance with a 100% duty cycle and column-mount capability — a practical solution where pad-mounting is not an option. It carries UL 325 and UL 991 safety listings and supports UL 325 Classifications I, II, III, and IV. The X390 includes two 4Ah batteries, positive stops, and a manual release mechanism, and offers 400 continuous cycles of battery backup.

Key Features

• Adaptive motor control
• Built-in thermostat-controlled heater
• Built-in voltmeter
• Lightning strike protection
• Multiple power options
• On-board display
• True battery back-up — 400 continuous cycles
• UL 325 compliant (Class I, II, III, IV)
• Two monitoring inputs with up to 4 devices per input
• Adjustable speed control
• Anti-tailgating feature
• Fail secure mode
• Adjustable timer for automatic closure
• High efficiency power supply
• Column-mount compatible
• Positive stops included
• Manual release — mechanical
• Two 4Ah batteries included

Specifications

• Maximum Gate Capacity: 14 ft at 600 lb
• UL 325 Classification: Class I, II, III, IV
• Duty Cycle: 100%
• Operating Voltage: 24VDC
• Voltage Current Specs: 120VAC – 1.5A or 240VAC – 1.0A (each motor)
• Main Power Frequency: 50Hz / 60Hz
• Main Power Fuse: 4A Timed
• Alternative Power Source: 24VAC / VDC (60VA) or Solar
• Accessory Power: 24VDC – 750mA
• Power Consumption (Sleep): 28mA
• Motor Current (Typical): 2.0A
• Operating Temperature: -20°F (-28°C) to 131°F (55°C)
• Opening Angle: 120°
• Gate Speed: 10–13 sec./90°
• Manufacturer's Warranty: 3 Years

The Viking Access Systems X390 Swing Gate Operator is built for reliable, long-term performance in professional installations.

What's Included

• (1) X-390 Swing Gate Operator

This listing is for the gate operator only. Remotes, receivers, photocells, and other accessories are sold separately.
