Viking Access Systems X390SLK Swing Gate Operator Single Kit
The Viking Access Systems X390SLK is a single swing gate operator kit rated for gates up to 14 ft at 600 lb, featuring a 100% duty cycle, built-in battery backup, and UL 325 Class I, II, III, IV listing.
Overview
The Viking Access Systems X390SLK Swing Gate Operator Single Kit delivers professional-grade performance for single swing gate applications. Powered by the V-Flex control board with speed control and a diagnostic LCD display, the X390SLK supports multiple power options, is solar efficient, and is ready for low voltage wiring for versatile installation. The operator can be mounted directly to a column — eliminating the need for a pad-mounted installation. It carries UL 325 and UL 991 safety listings.
Kit Includes
- (1) VA-X390 — X-390 Swing Gate Operator
- (1) VA-ECUS2 — ECU Single Controller for Kits
- (1) FA-XR2C — 433 MHz Receiver
- (2) FA-XT4RC — 433 MHz RC Transmitter
- (1) FA-XP30-10K — Photocell 10K Resistor
- (2) FA-XP30AC — Photocell Adapter
Key Features
- V-Flex control board with adjustable speed control and diagnostic LCD display
- Adjustable timer for automatic closure
- Built-in battery backup — 400 continuous cycles in case of power failure (two 4Ah batteries included)
- Built-in three-push button station
- Onboard lightning strike protection
- Adaptive motor control
- Built-in thermostat-controlled heater
- Built-in voltmeter
- Anti-tailgating feature
- Fail secure mode
- Multiple power outage options
- Manual release — mechanical
- Positive stops included
- Large box option available
- Column-mountable design
- Solar efficient and low voltage wiring ready
- Two monitoring inputs with up to 4 devices per input
- UL 325 Class I, II, III, IV and UL 991 listed
Technical Specifications
- Maximum Gate Capacity: 14 ft at 600 lb
- UL 325 Classification: Class I, II, III, IV
- Duty Cycle: 100%
- Operating Voltage: 24VDC
- Voltage Current Specs: 120VAC – 1.5A or 240VAC – 1.0A (each motor)
- Alternative Power Source: 24VAC / VDC (60VA) or Solar
- Accessory Power: 24VDC – 750mA
- Power Consumption (Sleep): 28mA
- Motor Current (Typical): 2.0A
- Main Power Frequency: 50Hz / 60Hz
- Main Power Fuse: 4A Timed
- Operating Temperature: -20°F (-28°C) to 131°F (55°C)
- Opening Angle: 120°
- Gate Speed: 10–13 sec./90°
- Battery Backup: 400 continuous cycles
The Viking Access Systems X390SLK is a complete single swing gate operator kit engineered for demanding professional installations.
