Access One Fire Lock Box for Knox Padlocks or Cores
The Access One FLB100 Fire Lock Box provides emergency access for automatic gates and pedestrian doors. It accepts Knox locks or padlocks and has a NO/NC/Common relay, vandal-resistant steel housing, stainless hinge, conduit knockouts, and fire red finish. 6" H x 4" W x 3" D; lock sold separately.
Access One FLB100 Fire Lock Box – Standard Size
The Access One FLB100 Fire Lock Box provides a secure and reliable solution for emergency access through automatic gates and pedestrian doors. Designed to accommodate both Knox locks and standard padlocks, this universal fire lock box allows installers to use a single enclosure for different emergency access requirements. Its rugged, vandal-resistant steel construction and high-visibility fire red finish make it well suited for outdoor commercial, industrial, and residential gate installations.
The FLB100 features a built-in relay switch with Normally Open (NO), Normally Closed (NC), and Common (C) contacts for integration with compatible gate operators and access control systems. When configured for padlock operation, removing the padlock activates the built-in switch, allowing the connected system to respond according to its wiring and programming. The lockable, hinged front door provides additional security while maintaining convenient access for authorized emergency personnel.
Key Features
- Universal Lock Compatibility: Accommodates Knox locks and standard padlocks.
- Built-In Relay Switch: Includes Normally Open (NO), Normally Closed (NC), and Common (C) contacts.
- Emergency Access Activation: Built-in switch activates when the padlock is removed, allowing integration with compatible gate or door control systems.
- Durable Steel Construction: Rugged, vandal-resistant steel housing with a stainless steel hinge.
- High-Visibility Finish: Fire red paint and UV-protected FIRE label for easy identification.
- Lockable Front Door: Hinged access door with a built-in cam lock.
- Convenient Installation: Built-in conduit knockouts on the back and bottom of the enclosure.
- Moisture Drainage: Weep holes allow accumulated moisture to drain from the bottom of the enclosure.
- Optional Status Monitoring: Compatible with the optional FBSM100 Status Module to indicate when the fire lock has been left on or held open.
Technical Specifications
- Manufacturer: Access One Technologies
- Model: FLB100
- Design: Standard Size Fire Lock Box
- Lock Compatibility: Knox Lock and Padlock
- Relay Contacts: NO, NC, Common
- Housing: Steel
- Hinge: Stainless Steel
- Finish: Fire Red
- Dimensions: 6" H x 4" W x 3" D
- Mounting Hole Pattern: 3" x 3" centered
- Back Conduit Knockout: 3/4" centered
- Bottom Conduit Knockout: 3/4" centered
- Optional Accessory: FBSM100 Status Module
Knox Lock Requirements
Important: The FLB100 does not include a Knox lock or padlock. Knox locks must be obtained separately through KnoxBox.com in accordance with your local fire department's requirements. Contact your local fire department to confirm the required locking configuration and obtain the appropriate authorization before ordering. Southeast Access Technologies does not sell Knox locks.
Always verify local fire department requirements and compatibility with the gate operator or access control system before installation.
