Linear GTO PRO SW3200XLS SEC SWING GATE

Overview

The Linear (GTO) PRO SW3200XLS Secondary Arm is the second operator arm for a dual swing gate system built on the PRO SW3200XLS. The PRO SW3200XLS series operates gates up to 16 ft long and 650 lb per leaf when installed per Linear's instructions.

Key Features

• 12 VDC, 120 W motor with 16:1 planetary gear drive
• Inherent obstruction sensing
• Soft start and soft stop for long mechanical life
• Pull-to-open or push-to-open, set at the control board
• Operation, diagnostic, and safety alarms
• Auto close adjustable from 3 to 120 seconds

PRO SW3200XLS Series Specifications

• Maximum gate: 16 ft (4.9 m) long and 650 lb (294.8 kg) per leaf
• Hinges: ball bearing hinges required on gates over 250 lb (113.4 kg)
• Opening time: 15 to 18 seconds
• Arm stroke: up to 16 in (41 cm)
• Operator length: 40.25 in (102 cm) fully retracted, mounting point to mounting point
• Current draw: 15 mA sleep; 3 to 7 A active
• Operating temperature: -5°F to 160°F (-21°C to 71°C)

This listing is the secondary arm only. Confirm compatibility with the existing primary operator before ordering.
