LIGHT TOUCH EXIT SENSOR

Overview

The Transmitter Solutions TRAKEYFREE is a battery-powered, wireless light touch exit sensor. A light touch on the sensor sends a 433 MHz rolling code signal to a compatible receiver, so no wiring is needed between the sensor and the receiver. It is IP55 rated for indoor and outdoor use.

Key Features

• Light touch activation
• Wireless 433 MHz rolling code with 2⁶⁴ code combinations
• Battery powered; battery life of 2 years
• Range over 500 ft; 656 to 1,312 ft in open space
• IP55 rated for indoor and outdoor use

Specifications

• Operating frequency: 433.92 MHz
• Modulation: AM/ASK
• Security protocol: 433 MHz rolling code
• Code combinations: 2⁶⁴
• Channels: 1
• Range in open space: 656 to 1,312 ft
• Battery type: R123A
• Operating voltage: 3 VDC
• Current consumption: standby 12 to 15 mA; transmission 20 mA
• Battery life: 2 years
• Operating temperature: -4°F to 176°F
• Enclosure rating: IP55
• Weight: 3.3 oz

Confirm receiver compatibility before ordering.
