All-O-Matic 4R-4 Main Pivot Bracket, Right-4"
The All-O-Matic 4R-4 Main Pivot Bracket, Right-4" is a hardware component for All-O-Matic overhead jamb-track systems used on tilt-up (California lift) gates. Left and right are determined from outside looking in.
All-O-Matic 4R-4 Main Pivot Bracket, Right-4"
The All-O-Matic 4R-4 Main Pivot Bracket, Right-4" is used in All-O-Matic overhead jamb-track hardware for tilt-up gates, also called California lift gates. It serves as a main pivot bracket, right-4" within a compatible jamb-track assembly. Select the matching size, orientation, and hardware configuration for the existing installation.
Product Details
- Part number: AOM-4R-4
- Part description: MAIN PIVOT BRACKET, RIGHT-4"
- Application: Overhead tilt-up / California lift gate jamb-track hardware
- Handing convention: Viewed from outside looking in
Handing: Left and right are viewed from outside looking in. The manual gives main-pivot-bracket alignment mark C as 40 inches (Short Set), 43 inches (Regular Long / Jumbo / Heavy Jumbo), or 49 inches (Heavy Jumbo Long), measured down from the top of the gate. Follow the applicable installation drawing.
Compatibility and Installation
Match the part to the applicable gate hardware set and manufacturer installation instructions. All-O-Matic states that jamb-track hardware must be installed and maintained by experienced, trained technicians; spring-loaded hardware can present serious injury risks when handled incorrectly.
