Magnetic ACCPRO-H-RC01540 RH Barrier, 15' MicroBoom, White
The Magnetic AutoControl ACCPRO-H-RC01540 is a right-handed barrier gate opener designed for boom skirt applications, including a 15 ft MicroBoom and MGC Pro controller in white powder-coated aluminum housing.
Overview
Designed and manufactured by Magnetic AutoControl, the ACCPRO-H-RC01540 is a right-handed barrier gate opener built with a taller cabinet that provides extra room for accessories. An optional barrier arm skirt (with or without climb-over prevention) can be added to help stop intruders from crawling under or climbing over the barrier. The unit ships with a 15 ft MicroBoom, an MGC Pro controller with LCD display, an integrated dual-channel loop detector, and a white powder-coated aluminum housing. It is rated for 10 million opening and closing cycles and backed by a 2-year warranty.
Key Features
- MHTM MicroDrive maintenance-free motor, motor, motor control, and gearing combined in one compact drive unit with high torque for operation in severe weather conditions
- MGC Pro controller with LCD display; EN 13849 compliant
- Integrated dual-channel loop detector
- 4.0-second open and close speeds
- Selectable opening and closing times
- Optional boom skirt can be added
- Maximum power consumption of 25W
- White powder-coated aluminum housing
- Rated for 10 million cycles
- UL & CSA Certified
- IP 54 protection class
Specifications
- Model: ACCPRO-H-RC01540
- Barrier Width: Maximum 15 ft (4.5 m)
- Opening/Closing Time: 4.0 seconds
- Cycle Rating: 10 million cycles
- Max Power Consumption: 25W
- Input Voltage: 110/115/120 AC (60 Hz, 1 Phase), 208 AC (60 Hz, 1 Phase), 208 AC (60 Hz, 3 Phase), 220/230/240 AC (60 Hz, 1 Phase), 230 AC (50 Hz, 1 Phase)
- Frequency: 50 / 60 Hz
- Temperature Range: -22°F to +122°F
- Protection Class: IP 54
- Dimensions (W x D x H): 12" x 14" x 44"
- Weight (without boom): 97 lbs
- Boom Length: 15 ft
- Color: White
- Certification: UL & CSA
- Alternate Part Number: Access Pro-H-LC01540
Important Notes
- Boom skirt sold separately
- A pendulum support or support post is required when using a boom skirt
Order the Magnetic AutoControl ACCPRO-H-RC01540 today for a reliable, high-cycle barrier gate solution engineered for demanding access control.
