Altronix AL600ULXB 12/24VDC 6A Power Supply/Charger

AL600ULXB Single‑Output Power Supply & Battery Charger (Board)

The AL600ULXB is a UL‑recognized, board-level power supply and charger, capable of converting 115 VAC / 60 Hz into a single 12 VDC or 24 VDC output with a 6 A continuous rating.

This board includes essential supervision and protection features: AC failure supervision, low battery detection, battery presence supervision, and short-circuit / thermal overload protection. It supports automatic switchover to a standby battery when AC is lost, with zero voltage drop during the transition.

Key Features

• 12/24 VDC selectable single output with 6 A continuous current capability
• UL recognized board design suitable for embedding or enclosures
• Battery charging & automatic switchover
• Supervision outputs: AC fail, low battery, battery presence (Form C contacts)
• Protection: Short-circuit and thermal overload safeguards built-in
• LED indicators for AC input and DC output status

Use Cases

This unit is perfect for power-only installations that don’t require switching or per-output control. For example, it can be used to supply a single gate controller, a security panel, or a set of locks when those devices handle their own control logic. Its fault detection and battery supervision features make it safety-ready for professional use.

Technical Specifications

• Input: 115 VAC, 60 Hz, 3.5 A
• Output: 12 VDC or 24 VDC (selectable) at up to 6 A continuous
• Features: Battery charging, zero-drop switchover, AC / battery supervision contacts, LED indicators, overload protection
• Operating Temperature: 0 °C to 49 °C (32 °F to 120 °F)

Conclusion

As a reliable and feature-rich single-output power board, the AL600ULXB delivers power, battery backup, and safety supervision in a compact, board-level form. It’s an excellent choice when you need regulated power and failover support without additional switching hardware.
