ProDataKey Rugged Single Gang Keypad/Reader, 125kHz Wiegand

PDK-RDRGRK Rugged Reader – Single-Gang Keypad, Prox, 125 kHz Wiegand

The PDK-RDRGRK is a ruggedized reader and keypad designed for demanding environments. Combining proximity card reading with a PIN keypad interface, it delivers both convenience and multi-factor authentication for access control systems. Engineered for outdoor durability, this reader supports 125 kHz proximity credentials and standard Wiegand output for easy integration.

Key Features

• Dual authentication: card + PIN keypad
• 125 kHz proximity support for PDK and HID® compatible credentials
• Wiegand output for seamless controller connection
• Single-gang mount for standard electrical boxes
• Weather- and vandal-resistant design (IK rating enclosure)
• LED and audible feedback for access status

Technical Specifications

• Frequency: 125 kHz
• Interface: Wiegand 26–bit
• Power: 6–14 VDC
• Dimensions: Single-gang (fits standard electrical box)
• Environment: Indoor/Outdoor, IP65 rated

Applications

Ideal for gates, exterior doors, and high-traffic entry points requiring enhanced durability. Integrates with ProdataKey Cloud Node and Red Controllers for secure, cloud-based access management.
