AES EL00C-RAD-K Commercial eLoop, Presence Mode, eTrans50
The AES EL00C-RAD-K is a wireless vehicle detection system in presence mode featuring dual sensor technology, magnetic field and radar detection, with 128-bit encryption and a range up to 50 yards.
Overview
The AES EL00C-RAD-K Wireless Vehicle Detect System is engineered for commercial settings, combining magnetic field and radar detection in a single compact unit. Presence mode keeps gates and barriers open when longer vehicles are detected over the detection area, improving safety and reducing the risk of collisions. The kit includes the e-Loop, eTrans50 transceiver, magnet, and concrete fixing bolts, making installation quick and straightforward.
Key Features
- Dual sensor technology: magnetic field and radar detection
- Presence mode for extended gate-open duration over detection area
- Range up to 50 yards
- High-security 128-bit encryption
- Compact profile, only 1.1" high x 8.6" diameter (IP68)
- Made of high-impact plastic with a 10 tonne static load limit
- 10,600 mA battery providing up to 6–10 years of battery life
- Quick and easy installation
e-Trans50 Transceiver Features
- Bidirectional wireless access control for gate and door applications
- Compact design with exceptional range
- SMA connector for optional long-range antenna connection
- 250 Hz bandwidth
- 128-bit AES encryption
- 2 x 1A relay contacts with NC/NO/COM outputs
- Selectable relay modes: Pulse, Latch, or Hold
- Suspension inputs for each relay
Specifications
- Frequency: 433.39 MHz
- Dimensions: 1.1" high x 8.6" diameter
- IP Rating: IP68
- Battery Capacity: 10,600 mA
- Battery Life: Up to 6–10 years
- Range: Up to 50 yards
- Static Load Limit: 10 tonne
- Relay: 2 x 1A contacts, NC/NO/COM
- Encryption: 128-bit AES
- Manufacturer Part Number: EL00C-RAD-K
The AES EL00C-RAD-K delivers reliable, long-lasting wireless vehicle detection purpose-built for demanding commercial applications.
